SMALL WIND TURBINES

REFERENCE PLANTS

Three blade rotor with tip speed ratio 7 and diameter 4,4m

24-pole PM synchronous generator

130kg total weight of nacelle, generator and rotor

8m mast height

15W electrical output at 2,6m/s wind speed

50W electrical output at 3m/s wind speed

280W electrical output at 5m/s wind speed

900W electrical output at 7m/s wind speed



















Three blade rotor with tip speed ratio 7 and diameter 8,4m

30-pole PM synchronous generator

280kg total weight of nacelle, generator and rotor

18m Mast height

15W electrical output at 1,5m/s wind speed

180W electrical output at 3m/s wind speed

1200W electrical output at 5m/s wind speed

3400W electrical output at 7m/s wind speed











































Two blade rotor with tip speed ratio 10 and diameter 4,4m

18-pole PM synchronous generator

85kg total weight of nacelle generator and rotor

10m mast height

15W electrical output at 1,9m/s wind speed

100W electrical output at 3m/s wind speed

340W electrical output at 5m/s wind speed

900W electrical output at 7m/s wind speed









































Two blade rotor with tip speed ratio 10 and diameter 8,4m

120-pole PM synchronous ring generator

160kg total weight of nacelle, generator and rotor

10m Mast height

15W electrical output at 1m/s wind speed

250W electrical output at 3m/s wind speed

1250W electrical output at 5m/s wind speed

3400W electrical output at 7m/s wind speed

































We will support you with consulting and planning and during project realisation.
