SMALL WIND TURBINES

KITS AND COMPONENTS

We offer you all essential components for your future small wind turbine composite in a kit.



A kit consists of:

(1) Planning and construction manual for getting the building licence and for installation.




(2) Wind turbine

  • rotor with 2 blades or 3 blades
  • housing with ywaing system
  • PM-generator
  • slip rings

















(3) Mast (-variants)



  • made of concrete
  • made of wood
  • made of metall











  (4) Control unit and inverter for feeding in a power gird





















Techncial data for wind turbines with 2 blade rotor:























 Small wind

turbine

type

Rotor-

diameter

[m]

Annual

electrical output

 (at a wind speed

of 4m/s)

[kWh]

Wind speed

for feeding in

[m/s]

Rotor-

speed

[rpm]

Weight

(rotor, housing

and generator)

[kg]

Sound level

in a distance

of 10m

[dBA]

SWT-2BR-3.4 3,4 900 2,5 ..... 25 <370 72 <48
SWT-2BR-4.4 4,4 1700 1,9 ..... 25 <285 96 <48
SWT-2BR-6.4 6,4 3300 1,5 ..... 25 <200 178 <48
SWT-2BR-8.4 8,4 5700 1,2 ..... 25 <150 184 <48












Techncial data for wind turbines with 3 blade rotor:























 Small wind

turbine

type

Rotor-

diameter

[m]

Annual

electrical output

(at a wind speed

of 4m/s)

[rpm]

Wind speed

for feeding in

[m/s]

Rotor-

speed

[rpm]

Weight

(rotor, housing

and generator)

[kg]

Sound level

in a distance

of 10m

[dBA]

SWT-3BR-4.4 4,4 1400 2,3 ..... 25 <190 130 <44
SWT-3BR-8.4 8,4 5200 1,6 ..... 25 <100 380 <44








We will support you with consulting and planning and during project realisation.
